• One 60’ x 80’ StageRight stage, black TechStage 4-by-6-1/2 foot variable height, and 2 12-by-24 foot sound wings.
• 4-foot StageRight free-standing mesh barricades.
• Wenger portable riser platforms: 12 pieces. - 4’ x 8’ x 8”; 12 pieces. 4’ x 8’ x 16”; 12 pieces. 4’ x 8’ x 24”.

Steel beams are located 60 feet from the floor with access above steel for riggers. All rigging plans, including desired hanging points, must be submitted to the Berglund Center Event Services department prior to tickets going on sale.

• 1800 amps power located in 3 backstage areas:
• 3 400 amp, 208 vac. 3 phase / 60 hertz, west / stage end
• 2 200 amp, 3 phase / 60 cycle, west / stage end
• 1 200 amp, 3 phase/ 60 cycle, northeast corner
• HVAC
• Forced air steam heating
• 800 tons of air-conditioning
• Chilled water in air handlers

Public address system located in the high steel supported with 9 sound delay speakers.

• 6 Carbon Arc Super Troupers
• 2 Xenon Super Troupers 2k
• 2 strong Xenon Gladiator 3k
• Located on north, south, and east light bridges.

The Eclipse is a half-house set-up using a house reduction curtain system. The Eclipse capacity is 4,276.

Hockey

• Dashers
• Glass
• Net
• Olympia ice resurfacing machine

Basketball

• Horner portable basketball floor
• 2 BPI backstops with Porter backboards and goals

A multi-purpose area is located backstage and can be used for dining for roadshows. Food service is available for up to 110 people.

Five dressing rooms and one officials room, each equipped with bath and shower facilities, are located in the immediate backstage area. Additional rooms available with advanced request.

The loading area is located at the west end of the building. Two doors measuring 22' x 15' provide access to the arena floor.

Club 611 is a private room located backstage and is open to Rail Yard Dawgs season ticket-holders and VIPs, as well as serving as the Green Room for most artists and tours.This uniquely appointed lounge pays homage to Norfolk & Western's famed 611 steam locomotive.We offer a menu of delectable foods and spirits created specifically for guests.The ambiance of this intimate lounge make visiting Club 611 memorable.Available for private rentals.

There is one office located in the immediate backstage area equipped with three telephone lines and 1 cable TV outlet.

• One dock is 10-by-9 foot, 8 inches, capable of handling 2 tractor-trailers at a time
• House has forklift and Genie available
• May need to forklift to move soundboard through front of house, depending upon size
• Trailers can be stored on-site at stage door
• Security is available upon request

• One section, adjustable by hydraulic lift
• Center line piano lift
• Apron overhangs US wall of pit 4 feet and 4 inches (distance from the upstage wall of the orchestra pit to the downstage edge of the apron)

• One Steinway Concert Grand - good condition
• One Steinway Baby Grand - very good condition
• One Yamaha Upright - good condition
• Professional tuner available with advance notice

Located at rear stage corridor. One washer and dryer available upon request.

• Storage for set pieces measured from proscenium opening to first obstruction
• Stage Left Wing - 20-by-25 foot, patch board downstage
• Stage Right Wing - 25-by-55 foot, fly ropes

2 full-service ticket offices are located in the BPAT.

• Manual, operates as a guillotine or traveler from stage right deck
• 2 back drops - 1 black and 1 blue cycle
• 4 sets of Legs: 30-by-12 feet, black.
• 4 borders: 5-by-60 feet, black

• Single purchase counter-weight system, hand operated
• Up to 10,000 pounds available
• 44 line sets. Arbors - 1,000 pound capacity for counter-weight system.
• Chain hoists available via rental

• House is equipped with a Soundcraft 200 Delta 24 x 4 x 2 mixing console located in the rear of the Theatre.
• Soundboard has 12 inputs and 1 auxiliary output
• There are 4 15 inch Altec 70v speakers
• Lines are run to light booth, fly floor, sound booth, follow spots, stage right, stage left, house and projection room.
• We also have an Otari MX5050 reel-to-reel, 7-1/2 ips and 15 ips
• There is a Clear-com 3-pin intercom system
• Cable can be run 215 feet from stage to road console in rear theater seating area
• XLR connectors only

Over Stage

• 1 10-foot movie screen
• 1 traveler, located mid-stage Line 27
• 2 electric pipes on Lines 5 and 43
• 1 cyclorama
• 1 fire curtain
• All can be moved with advance notice except for the electric pipe.

On Deck

• One 66’ loading bridge, located stage right grid
• 1 adjustable proscenium

2 Strong Xenon Super Trooper 6k Follow Spots located in the rear balcony, not removable.

• 12 - 12-by-22 inch 1 killowatt Major (2nd cove ceiling)
• 2 - Strong Super Xenon (rear balcony)
• 12 - 8 inch Leko Kleigs 750 watt (1st cove ceiling)
• 12 - 6 inch (6-by-9) Lekos 750 watt (Stage slots - left and right - 6 per side)

• 10 - 6 inch Fresnels 750 watt
• 8 - Scoops 1000
• 6 - 8 inch Fresnels 750 watt
• 5 - ETC 190° (6-by-16) Leko
• 2 - ETC 360° (6-by-9) Leko
• 1 - 10 inch Fresnel 750 watt
• 34 - (6 x 9) Lekos 750 watt
• 4 - Beam Projectors 1000 watt
• 36 - 1 kilowatt Par cans

The house has own dimmers and an ETC Insight lighting console with 108 channels. Board has 52-6kw, 8-12kw, 5-6kw and 5-12kw non-dim capacity. Circuits per dimmer varies according to wattage. Permanent FOH lighting controlled from lobby. House lights controlled from stage right and do not transfer to control stage lights.

• 46,000 square feet total
• 300-by-150 feet with 6 columns
• Ceiling height is 32 feet

• 8-by-10 foot booths = 273 (booths without concessions = 281)
• 10-by-10 foot booths = 229 (booths without concessions = 237)

Available as a lobby for guests entering the Center

• two permanent concession stands located on both the north and south walls
• Portables also available for additional points of sale

two ticket offices - 1 at the north entrance and 1 at the south entrance

• two sets of men’s and women’s restrooms in and near the Special Events Center,
• one set of men’s and women’s restrooms located in the Pre-Function Area located on the north wall

Three show offices are available for use by clients.
